Ford Jaguar GT1749V Turbo 714467-5014S 714467-0014 Duratorq DI

Product Description

Part Number    714467-5014S

Previous Version    714467-0003, 714467-0004, 714467-0005, 714467-0007, 714467-0008, 714467-0012 , 714467-0013, 714467-5013S

OE number    2S7Q6K682AG, 2S7Q6K682AC, 2S7Q6K682AE, 2S7Q6K682AF, 2S7Q6K682AD, 3S7Q6K682AE, 3S7Q6K682AF, 1383646, 3S7Q6K682AD, 1435150, 2S7Q6K682AJ, 1132648, 1202122, 1219649, 1256751

Year    01-05

Description    Ford Mondeo III, Jaguar X Type

CHRA    433395-0030 (433395-0025)

Turbo Model    GT1749V, GTA1756

Engine    Duratorq DI

Engine Manufacturer    Ford

Displacement    2.0L, 2000 ccm, 4 Cylinders

KW    96/130 HP

RPM Max    4000

Fuel    Diesel

Bearing Housing    722282-0077

Turbine Wheel    434533-0006

Comp. Wheel    702489-0002

Back plate    700593-0003

Heat shield Number    433112-0001

Turbine Housing AR    VNT2

Gasket exhaust manifold    210538

Gasket (turbine outlet)    210537

Gasket (oil outlet)    210243

Gasket actuator EGR    210546

Settings Waste gate (pressure)    0.264-0.269 bar

Settings Waste gate (lift rod)    0.5-2.5 mm

Manufacturer    Honeywell-Garrett

Applications

2001-05 Ford Mondeo TDCi with Duratorq DI Engine

2001-05 Ford Ford Transit V with Duratorq DI Engine

2001-05 Jaguar X Type with Duratorq DI Engine

Packing
