GTA5018S Turbo 774451-0004 23538880 23538881 774451-5004S Turbocharger for Detroit Diesel Industrial Engine, Truck, Various

Note: Pictures are only for reference,Logo and color base on production line,we just promise good quality of item.

Inquire Online

Product Description

Part Number	774451-5004S
Previous Version	774451-0004, 774451-0001, 774451-0003, 774451-4
OE number	23538880, E23538880, R23538880, E23538259, 23538259, 23538881, R23538881, E23538881
Description	Industrial Engine, Highway Truck, Various
CHRA	712371-0194 (712371-5194S)
Turbo Model	GTA5018S, GTA5018
Engine	S60 Diesel
Displacement	14.0L, 1400 ccm, 6 Cylinders
KW	496/665
RPM Max	2300
Fuel	Diesel
Angle α (compressor housing)	145º
Angle β (turbine housing)	90º
Bearing Housing	706666-0043 (Oil Cooled)
Turbine Wheel	451938-0008 (451940-0002)(Ind. 101.98 mm, Exd. 111.22 mm, 10 Blades, Boreless)
Comp. Wheel	781770-0003 (Ind. 81.83 mm, Exd. 123.3 mm, 7+7 Blades, Billet)
Backplate	706668-0025
Heat shield Number	407843-0001
Repair Kit	NEW IN STOCK
Turbine Housing	447937-0070
Turbine Housing & W/G	743732-0051
Compressor Cover	446608-0152
Turbine Housing AR	1.41
Actuator	729592-0006
Wastegate Bushing	430072-0002
Wastegate Arm & Valve Assembly	430453-0091
Wastegate Crank Assembly	430311-0010
Actuator Mounting Bracket	743818-0001
Wastegate Plug	447259-0004

2010- turbocharger for Detroit Diesel Industrial Engine, Truck Various With Series S60 Engine
