Product Description

Part Number 54399880024
Previous Version 5439-988-0024, 5439 988 0024, 54399880026
OE Number 038253014E, 038253019S, 038253019SX, 038253019SX, 038253019SV
Year 2003-
Description Volkswagen Beetle
Manufacturer Part Number 54399700024, 54399700026, 5439-970-0024, 5439-970-0026
CHRA 54397108001 (5439-710-8001, 1303039908)
Turbo Model BV39-1873CCB426.18BVAXC, KP39-0024/26, KP39-1873CCB/426.10
Engine Code BEW
Engine Manufacturer VW
Displacement 1.9L TDi, 1896 ccm
KW 74/101
RPM Max 4000
Fuel Diesel
Angle α (compressor housing) 93
Angle β (turbine housing) 90
Bearing Housing 54391504013/53041500017
Turbine Wheel 54391205011
Comp. Wheel 54431232007/54431232012
Back plate 54431523000
Heat shield Number 54391652001
Turbine Housing AR VTG
NOTE VTG, Intercooler, integrated manifold; restricted to VW group
Manufacturer Borg Warner - 3K - Schwitzer, BWTS DE

Applications
2003- Volkswagen Beetle with BEW Engine
